Electronic connector is a device that connects two electronic products to each other. Its function is to connect two circuits and transmit current or signal in two circuits. USB data line and socket are typical electronic connectors. An electronic connector may also be fixed inside an electronic product to connect parts within the product. The following small series for you to introduce the classification and use of electronic connectors:
1. Rectangular connector
The plug and socket in the rectangular connector are connected with threaded guide rod and have locking device, which are mainly used for electrical connection of electronic equipment, intelligent instrument and electronic control equipment.
2, water pressure sealing connector
These connectors are mostly circular connectors and are suitable for circuit connections that work in water or in harsh environmental conditions.
3, rf coaxial connector
Rf coaxial connector is a small threaded locking connector, with small size, light weight, easy to use and other characteristics, suitable for radio equipment and electronic instruments in the high frequency circuit for the connection of RF cable. Electronic connector its operating frequency is generally up to 500MHz.
4. Concentric connector
Concentric connector is a small plug socket connector, which is small in size and has the function of a switch. Concentric connector is suitable for low frequency circuit, mainly used for connecting earphone, microphone and external power supply.
5. Column connector
The number of leads of a column connector is generally less than dozens. Electronic connectors are suitable for the circuit connection of printed circuit boards and devices in the equipment.
6. Printed circuit connectors
Printed circuit connectors are mainly used to connect printed circuit boards in electrical or electronic equipment.
7. Ribbon cable connector
The socket of strip cable connector is directly welded on the printed circuit board, the plug and strip cable are puncture crimped, which can be completed at one time, reliable contact, easy to use, suitable for the connection of instrument and meter circuit.
8. Circular connector
The plug and socket of the circular connector are mostly connected by thread, and the terminals can range from two to hundreds. It has the characteristics of small volume and high reliability, and can meet the needs of cable connection between electronic devices.
